Sabmadi Federal Armed Forces
Ground Vehicles
Char Leclerc Series XXI-S
(Produced on License)
General Characteristics
Role: Main Battle Tank
Crew: 3 (Commander, Gunner, Driver)
Length: 9.875m
Width: 3.60m
Height: 2.53m
Mass: 57.6 Tons
Mobility 71 km/h on-road with a range of 550 km
Powerplant: V8X SACM 8-cylinder diesel engine Producing 1,500 hp w/ a Horsepower to weight ratio of 27.52
Protection;
Modular composite Armor including titanium and semi-reactive layers.
Armament:
GIAT CN120-26/52 120mm Cannon w/ 40 rounds (1 round ready to fire in the chamber, 22 rounds inside the autoloader magazine with additional 18 rounds cylinder in the hull)
1x 12.7mm coaxial M2HB machine gun (1,100 rounds)
1x 7.62mm machine gun (3,000 rounds)
Combat Vehicle 90
General Characteristics
Role: Infantry Fighting Vehicle/SPAA
Crew: 3 (Commander, Gunner, Driver) +8 Troops
Length: 6.55m
Width: 3.10m
Height: 2.70m
Mass: 37 Tons
Mobility 70 km/h on-road with a range of 320 km
Powerplant: Scania DC16 16 liter diesel V8 engine Producing 1,073 hp w/ a Horsepower to weight ratio of 24.1
Protection;
Modular composite Armor including titanium and semi-reactive layers. Provides protection against rounds up to 30mm APFSDS.
Hard-Kill Active Protection System w/ 4th Generation electronic architecture.
Armament:
40mm Bofors L/70 autocannon (Can be mounted with a TRIAD Turret mounting a high-velocity 40mm and radar system.)
1x 7.62mm machine gun (3,000 rounds)
6x 76mm Grenade Launchers
Pandur 8x8 APC
General Characteristics
Role: Armored Personnel Carrier
Crew: 2 (Gunner, Driver) +12 Troops
Length: 7.35m
Width: 2.67m
Height: 2.08m
Mass: 14.5 Tons
Mobility 105 km/h on-road with a range of approx. 700km
Powerplant: 6-cylinder in-line liquid-cooled turbo-charged intercooled diesel
Protection;
Modular composite/Applique armor providing protection up to 12.7mm for standard package, and 30mm APFSDS for Motor Gun System Package
Armament:
Variable main armament in a CROWS Mount: (12.7mm HMG for APC, 105mm for Motor Gun System, 30mm Skyranger 30 System w/ FIM-92 Stinger/Mistral Missile launcher)
7.62mm Coaxial Machine Gun
2x Spike LR Anti-Tank Guided Missile Launcher
MIM-104 Patriot Surface-to-Air Missile System
General Characteristics
Role: ABM/SAM System
Crew: 6
Length: Varies by vehicle
Width: Varies by vehicle
Height: Varies by vehicle
Mass: Varies by vehicle
Mobility 65 km/h on-road w/ operational range of ~500km
Powerplant: Varies by vehicle.
Protection;
Varies by vehicle, generally resistant to small arms only.
Armament:
4x or 16x PAC-2/3/3MSE Missile Systems
Missile Flight Altitude: 24.2km
Maximum Speed: PAC-1: Mach 2.8. PAC-2/3: Mach 4.1
M142 HIMARS
General Characteristics
Role: MLRS
Crew: 3
Length: 7m
Width: 2.4m
Height: 3.2m
Mass: 16,250kg
Mobility 85 km/h w/ a range of 480km
Powerplant: Caterpillar 3116 ATAAC 6.6-liter diesel
Protection;
generally resistant to small arms only.
Armament:
6x MLRS
1x ATACMS
2x PrSM
Oshkosh JLTV
General Characteristics
Role: Utility Vehicle/MRAP
Crew: 1+3+1 optional gunner
Length: 6.2m
Width: 2.5m
Height: 2.6m
Mass: 10.27 Tons
Mobility 110 km/h
Powerplant: Gale Banks 866T 6.6-liter Diesel w/ Allison 2500SP six-speed automatic transmission
Protection;
Composite/aluminium-applique armor plating (A/B Kit configuration) Resistant up to 12.7mm .50 BMG AP rounds
Armament:
Various light and medium caliber weapons, including the M2HB Browning HMG, Mk.19 AGL, or I-TOW ATGM.
M109A7 Paladin SPG
General Characteristics
Role: Self-Propelled Artillery
Crew: 6 (Commander, Driver, Gunner, 3 Loaders)
Length: 9.1m
Width: 3.15m
Height: 3.25m
Mass: 38.1 Tons
Mobility 61 km/h
Powerplant: V903 producing 675 horsepower with an Allison XTG-411-2A Transmission
Protection;
Aluminum Alloy
Armament:
M284 155mm Howitzer w/ 36 rounds of ammunition.
1x .50 BMG M2HB Heavy Machine Gun
Armament Range:
HE: 21km
RAP: 30km
Excalibur: 40km
